New 100 Pack One Channel Passive video transmitter up to 1000FT Mini : Use this convenient adapter to easily convert your video signals from one format to another. U.S. Security Solutions high quality adapters allows you to make two different video devices compatible with minimal effort. The precise manufacture of these adapters ensures a clear connection eliminating all possible loss of signal. You will be both amazed and satisfied with the quality of video provided by these quality video adapters.

The Device is Capable of Receiving and Transmitting Video Signals Over UTP Wire. Can Be Used With DVR/Quad, Easy to Transfer Camera Video and PTZ Control Signal over Long Distance. Enables Cost-Effective, Point to Point Transmission Application. Adopts Twisted Pair Wiring, Which is Low Cost and Easily Obtainable. With Noise Interference Restrain Design and Permitting Stable Image. Video interface Usage Either camera or monitor side Device category passive   Connector for camera/monitor: BNC Male Connector for the wires terminal block Maximum Distance 1000 ft Wiring Wire required: CAT5, CAT6, or phone cable Connector type: terminal block Power AC Adapter Requirement no power needed Remote power transmission: none Dimensions and Weight Dimensions 1.38" long x 0.63" wide x 0.63" high (34mm x 16mm x 16mm) Weight 0.7 oz (18 g) Technical specifications Frequency response DC to 6.5 MHz Attenuation RL = 75 to 100: 0.4 dB RL = 75 to 600: 1.2 dB Impedance Coax - 75 ohm UTP / telephone cable - 100/600 ohm Coax unbalanced, 75 ohm UTP C5E Balanced twisted pair, 24AWG/ 100 ohm Telephone cable Balanced twisted pair, 26-28 AWG, 600 ohm We offer UPS shipping ground, three days select and Over night No P.O. Box Please
