New Multi functional CCTV Tester W-MT100 : Used by installers and field technicians, handheld W-MT100 can test video, RS485 data, and status of UTP cables connection. Portable solution, able to withstand harsh environments, supports RS232, RS422 simplex, RS485, and multi-protocol formats. It also tests RS485 data sent from controlling device and displays hexadecimal data content on integral LCD screen. Powered via included adapter or internal battery, tester can be used while being charged and is operated via OSD.

Hover Your mouse over the small images to enlarge

Crystal & Clear Image: 2.5" Inch LCD Support RS232 and RS485 synchronically Auto-reduce power consumption. Low power consumption / once charged, the power can be used for 4-5 hours. Built in OSD Yesr LED Indicator Yes Internet Line Test Yes Low power consumption once charged, the power can be used for 4-5 hours. Rechargeable battery Yes (4) included PTZ Control Yes Cable Tester Yes Communication Port RS232/RS485 Video Input /Output Selectable Communication Selectable Baud Rate Selectable LCD 2.5 Inch LCD Video Format NTSC / PAL AUTO Switch Interior Power (10%) DC 3.6 1200MAH Exterior Power  (10%) DC9V 2amp Dimensions (mm)** 156(L) x93(H) X51 (W) We offer UPS shipping ground, three days select and Over night No P.O. Box Please
