Home > CCTV Cameras > P.T.Z Cameras > New High Speed 6 In One Auto Tracking Dual Output IR PTZ 30X Time Optical 32X Time digital Zoom 4 Megapixel Progressive Scan True Digital 1080p
|
New High Speed 6 In One Auto Tracking Dual Output IR PTZ 30X Time Optical 32X Time digital Zoom 4 Megapixel Progressive Scan True Digital 1080p
|
US-PHD10IR300X
|
|
U.S Security Solutions High Speed US-PHD10IR300X 4MP Auto Tracking 1080P 2 in 1 HD-SDI / HD-TVI / HD-CVI/ AHD / Analog D1/ 960H White 30X Optical 32X digital
|
List Price: $2,399.99
Your Price: $1,199.99
You Save: $1,200.00 (50 %)
Out of stock
Detailed Description
New U.S Security Solutions High Speed US-PHD10IR300X 4MP Auto Tracking 1080P 6 in 1 HD-SDI / EX-SDI / HD-TVI / HD-CVI / AHD / Analog D1/ 960H Dual output White 30X Optical 32X Digital Pan Tilt Zoom Outdoor 7 Super High Array LED PTZ With 4.3-139MM Lens: This PTZ is Full High definition 1080P 30FPS Dual output 6 in 1 Camera employs 1/3" 4Mega pixel Sony Progressive Scan CMOS sensor Eynix EN773E DSP for extreme clarity and superb picture quality day and night. A 360 pan 130 tilt 30 Time optical Zoom 4.3MM -139MM Vari Focal 4MP motorized Lens 32X digital Zoom for quality Full HD 1920 X 1080 1080P resolution that meet todays need. A built in 7IR Super High Array LED and IR Cut sensor for true coloring and superior night vision operations. Aluminum body and wall mounting BOX Bracket design as well as built in power converter insure long life, flawless operation and quality installation
Built in OSD allow for full control of the Auto Tracking functionality, Motion detection, Timer, Scan, Preset, Run camera in 720P or 1080P mode, set Farm per second , enable Full Wide Dynamic Range, HTS, fog control, Digital zoom, freeze, Mirror , AGC, 3D/2D NR, built in SD out for easy install and adjustment.
Quality 7IR Super high power Array LED night vision provide over 150 meters (400 Feet) of night vision range , Easy install with built in Full OSD, Built in Surge and Wave protection, Ground connection ready , Alarm with 8 Input and 4 Output, 255 preset , 8 Auto Scan , 8 Touring , 2 Auto Tracking Pattern Support.
The new 1/3" 4 MegaPixel Sony Progressive Scan CMOS Color imaging sensor, Eynix EN773E full WDR DSP processor and 7IR Array cut Sensor which provides extremely long life and high reliability. A combination that is second to none in quality Imaging and superior Night vision 10IR Super LED high power Array effective range reaches up to 150 meters (400 Feet) The only HD-SDI High Speed Dome Camera in the market with An Industrial Grade Outside Working Temperatures pan from -30F to +50F simply the best on the market.
Upgrade your PTZ imaging quality with this Full HD 1080P 30 Time Optical 4.3MM -139MM Vari Focal 4MP lens staring from 4.3MM to 139MM close-ups Outdoor weatherproof IR Speed Dome Camera provides up to 3000 TV lines Resolution This IR PTZ Camera is suitable for Day & Night surveillance with clear and sharp images.
Buy directly from U. S. Security Solutions a U.S.A Company a manufacturer specialize in CCTV camera recorder and accessories outstanding service and warranty, best quality product exactly as specified and described at affordable price, tested to be the best.
Hover Your mouse over the small images to enlarge
| |
Full HD 1080P resolution, 1/2.8” 4MP Sony Starvis CMOS image sensor; 30FPS |
| |
6-in-1 design, integrating AHD/TVI/CVI/HD-SDI/EX-SDI /CVBS into one single speed dome camera; |
| |
F4.3MM -F139MM Powerful 30x optical zoom and 32x digital zoom; |
| |
Simple DIP Switch for switching video signal outputs of AHD/TVI/CVI/HD-SDI/EX-SDI/CVBS; |
| |
Control PTZ camera movement and transmit video over a single coaxial cable(UTC); |
| |
Micro-Stepping technology makes PT motion smoother, especially at maximum optical zoom ratio; |
| |
Compound Movement makes the speed dome reach the preset in the shortest route; |
| |
Full 360° continuous pan rotation for complete area coverage; |
| |
Maximum PT manual speed up to 300°/s, accuracy up to +/-0.01°; |
| |
Support 255 presets, 8 scans, 8 patterns, 8 groups, 16 schedules, 8 privacy masks; |
| |
Auto focus/Auto flip/Auto protocol identification/Power up; |
| |
True Day & Night HLC / BLC / WDR DIS / Defog; |
| |
OSRAM IR LED lights enhance sensitivity during night, IR distance up to 150 meters; |
| |
Protection against lightning strikes and power surges, Weatherproof for outdoor & indoor installation (IP66 Rated). |
| Model |
US-PHD-10IR300X |
| Pick-up Element |
1/3" 4MP Panasonic Progressive Scan sensor & Eyenix EN773E DSP |
| Number of Pixels |
1920(H) x 1080(V) <NTSC> / 1920(H) x 1080(V) <PAL> |
| Resolution |
3000TVL Lines though HD-SDI / 2000TVL Lines though HD-TVI/HD-CVI/AHD / 1000TVL Line through Analog D1/960H |
| Min. Illumination |
Color:0.2Lux, BW:0.05Lux; Color DSS:0.002Lux,BW DSS:0.001Lux |
| Day/Night |
Auto/Day/Night |
| Focus |
Manual/Auto / One Push |
| Iris |
Auto/Manual |
| Shutter Speed |
1/30(25) sec ~ 1/300,000 sec |
| Speed |
Max.300 °/sec (proportional to zoom ratio) |
| DSS |
Auto/Off |
| White Balance |
Auto/Indoor/Outdoor/Manual |
| Pan/ Tilt Angl |
Pan: 360°endless, Tilt: 130° |
| Mirror |
None/Horizontal/Vertical/Horizontal & Vertical |
| HLC/WDR/BLC/DIS/Defog |
On/Off |
| Privacy Mask |
8 privacy masks programmable |
| Zoom Ratio |
30x Optical zoom, 32x digital zoom |
| Focal Length / Iris |
f=4.3(Wide) – 139(Tele)mm / F=1.6(Wide)-5.0(Tele) |
| PTZ Function |
Preset up to 255/Auto Scan 8 /Pattern 8 /Group 8 /Schedule 16 /RS 485 Support/ UTC Support /Auto Flip /Parking Action
Auto protocol identification /Power up Action |
| Alarm In/Out |
8CH/4CH |
| Alarm Trigger Event |
Alarm out, preset, scan, pattern, group |
| Protocol / Baud rate |
Pelco D/P , 2400/4800/9600 bps |
| IR Function |
IR radiation distance; Approximately 150m
Infrared mode; Auto/ Manual/ Semi-Auto
IR LED layout; OSRAM IR LED for Near:2; Middle:2; Far:3; 7 Leds in total.
IR LED power; Each max. 2.3W
IR LED current; 1A |
| Dimension |
Main unit without mount bracket: Φ185mm*288.5mm. |
| Net Weight |
2.8 Kg(Only PTZ dome without mount bracket) |
| Gross Weight |
5.2Kg (with wall mounting bracket ) |
| Working Temp. |
-30°C ~ +50°C; |
| Working Humidity |
90% (Non-condensing) |
| Video Output |
Dual Video Output;
1- Selectable Digital HD-SDI/EX-SDI
2-Selectable Analog HD-TVI /HD-CVI/AHD/CVBS Analog D1 960H |
| Fan |
Yes |
| Power Supply |
DC12V /AC 24V |
| Power Consumption (10%) |
AC24V: 40W Max., DC12V: 36W Max. |
| Service Power Supply Output |
Built in DC12V/500mA |
| IP Rating |
IP66 |
| Protection Grade |
Power 6000V, Video 6000V, RS 485 6000V
Certificate; CE, FCC |
| Manufacturer |
U.S. Security Solutions |
| U.S. Warranty |
One (1) Year Limited Warranty |
